The Osprey Multi-Spectral Binocular merges high-performance thermal detection and digital night vision into a single, compact system built for clarity and range. Users can select between 384x288 or 640x512 thermal sensors, each offering ≤25mK NETD for excellent thermal contrast and detection accuracy in challenging environments.
With Picture-in-Picture (PIP) mode, users can view thermal and night vision images simultaneously or switch between modes independently. The Osprey’s built-in 1200-yard laser rangefinder (LRF) provides precise distance measurement, while the integrated 850nm IR illuminator enhances visibility up to 350 yards in low-light or total darkness.
Featuring a 35mm objective lens, 25mm eye relief, and 640x480 video resolution, the Osprey delivers sharp, comfortable viewing. Its IP67-rated aluminum alloy body ensures reliability in all weather conditions, and a replaceable 21700 Li-Ion battery powers up to 6 hours of operation.
Additional functions include an electronic compass, microphone, Wi-Fi connectivity, multiple image modes, and photo/video recording to a 128GB micro SD card (removable). Designed for rugged field use, the Osprey Multi-Spectral Binocular provides unmatched versatility, precision, and endurance for professionals and outdoorsmen alike.
Model Differences
The Osprey 384 model offers a 384x288 thermal sensor for dependable clarity and solid performance in typical hunting and observation conditions. It’s ideal for users who want professional-grade thermal capability at a more accessible price point.
The Osprey 640 model upgrades to a 640x512 thermal sensor, delivering finer detail, greater detection range, and superior contrast when identifying heat signatures at long distances or in complex environments. The 640 variant is best suited for users demanding maximum precision and image clarity.
Shipping: Confirmed orders will be shipped within 2 business days from our US warehouse
Warranty: 5 Years for Thermal Imaging models (Registration needs) & 2 years for Night Vision models
- Models:
- Osprey 480, Osprey 640
- Classification:
- Multi-spectral Binocular
- Heading:
- Thermal Sensor
- Thermal Sensor Type:
- Uncooled Vox (vanadium oxide)
- Osprey 480 Resolution(px):
- 480*360
- Osprey 640 Resolution(px):
- 640*512
- Pixel Size(µm):
- 12*12
- NETD:
- ≤20mK（0.020℃）
- Frame Rate(Hz):
- 50
- Detection Distance(m):
- 1800
- Thermal Sensor Image Engine:
- Pard IREA
- Objective Lens(mm):
- 35
- Osprey 480 Optical Magnification(x):
- 2.4
- Osprey 640 Optical Magnification(x):
- 1.8
- Digital Zoom(x):
- 2/4/6/8
- Osprey 480 Field of view (HxV) Horizontal:
- 9.4°
- Osprey 640 Field of view (HxV) Horizontal:
- 12.5°
- Osprey 480 Field of view (HxV) Vertical:
- 7.1°
- Osprey 640 Field of view (HxV) Vertical:
- 10.0°
- Osprey 480 Field of view (HxV) Diagonal:
- 11.8°
- Osprey 640 Field of view (HxV) Diagonal:
- 16.0°
- Thermal Sensor Focus Range:
- 3m-∞
- Heading:
- Thermal Sensor Display
- Thermal Sensor Display Type:
- LCD
- Resolution(px):
- 640*480
- Scene Mode:
- City/Rain/Forest
- Image Mode:
- WT-HOT/BK-HOT/EDGE/RD-HOT/IN-
- Eye Relief(mm):
- 5
- Diopter adjustment(D):
- -5~3
- Heading:
- Visible Light Sensor
- Osprey 480 Resolution(px):
- 2688*1520
- Osprey 640 Resolution(px):
- 2688*1520
- Pixel Size(µm):
- 2.9
- Sensitivity(lux):
- 0.001
- Frame Rate(Hz):
- Color:60/Mono:30
- Visible Light Sensor Image Engine:
- Pard IREA
- Objective Lens(mm):
- 50
- Optical Magnification(x):
- 3.5
- Digital Zoom(x):
- 2/3
- Field of view (HxV) Horizontal:
- 6.4°
- Field of view (HxV) Vertical:
- 4.8°
- Field of view (HxV) Diagonal:
- 8°
- Visible Light Sensor Focus Range:
- 3m-∞
- Heading:
- Visible Light Sensor Display
- Visible Light Sensor Display Type:
- LCD
- Visible Light Sensor Display Resolution(px):
- 640*480
- Visible Light Sensor Display Scene Mode:
- City/Rain/Forest
- Visible Light Sensor Display Image Mode:
- WT-HOT/BK-HOT/EDGE/RD-HOT/IN-
- Visible Light Sensor Display Eye Relief(mm):
- 25
- Visible Light Sensor Display Diopter adjustment(D):
- -5~3
- Heading:
- Photo / Video
- Photo Resolution(px):
- Thermal: 2048*1536/Night Vision: 2048*1536
- Photo Format:
- .JPG
- Video Resolution(px):
- Thermal: 1024*768/Night Vision: 1920*1440
- Video Format:
- .mp4
- Storage:
- Micro SD card (128 GB,Max)
- Heading:
- Main function
- LRF Detection Range:
- 1000m/1200yd
- PIP:
- Yes
- Gyroscope:
- Yes
- Loop Recording:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical shutter
- Microphone:
- Yes
- Firmware Upgrade:
- Yes
- Heading:
- Interfaces
- USB Tpye-C:
- Yes
- HDMI Output:
- Yes
- WiFi:
- Yes
- Supported Apps:
- PardVision2
- Heading:
- Power Supply
- Battery Type:
- Lithium Ion 21700*1
- Output Voltage(V):
- 3.7
- Operating Time(h):
- ≤6
- External Power Supply:
- Type-C
- Heading:
- Environmental Characteristic
- Protective Class:
- IP67
- Operating Temp(°C/°F):
- -30 ~ +55 / -22 ~ +131
- Recoil Resistance(J):
- 6000
- Heading:
- Material
- Objective lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Product dimension(with IR illuminator&LRF, L x W x H,:
- 220*137*58
- N.W/pcs(with LRF&battery, g):
- 704.5
