The TD32 features a 384x288 thermal sensor, while the TD62 is equipped with a 640x512 uncooled Vox IR sensor—delivering sharp target identification and high-resolution detection. This advanced multispectral device combines thermal imaging with night vision, allowing users to view both simultaneously via a unique PIP mode on an 800x800 IPS LCD display. It includes a 1200-yard laser rangefinder that integrates with an onboard ballistics calculator, automatically adjusting reticle aim. The TD's visible light sensor (1920x1080 CMOS) offers performance down to 0.001 lux using a 70mm lens, while the VCSEL IR illuminator provides 3 intensity levels and a directional beam up to 383 yards (350m). Additional highlights include a removable 128GB Micro SD card, wireless connectivity via the PardVision app, USB-C & HDMI support, and rugged IP67 protection. Weighing just 28oz (800g), it's recoil-rated to 6000J and supports operation in temperatures from -4°F to 122°F.
- Models:
- TD32-70, TD62-70
- Classification:
- Multi-spectral Thermal/Night Vision Scope.
- Heading:
- Thermal Sensor
- Type:
- Uncooled Vox IR Sensor
- TD32-70 Resolution(pixel):
- 384*288
- TD62-70 Resolution(pixel):
- 640*512
- TD32-70 Pixel Size(µm):
- 12*12
- TD62-70 Pixel Size(µm):
- 12*12
- NETD:
- ≤25mK（0.025℃）
- Frame Rate(Hz):
- 50
- TD32-70 Human Detection Distance(m):
- 1400
- TD62-70 Human Detection Distance(m):
- 1800
- TD32-70 Vehicle Detection Distance(m):
- 2600
- TD62-70 Vehicle Detection Distance(m):
- 3300
- Image Engine:
- PARD IREA
- TD32-70 Objective lens(mm):
- 35
- TD62-70 Objective lens(mm):
- 45
- TD32-70 Optical Magnification(x):
- 3
- TD62-70 Optical Magnification(x):
- 2
- Thermal Sensor Digital Zoom(x):
- 2
- TD32-70 Continuous Digital Zoom(x):
- 3-6
- TD62-70 Continuous Digital Zoom(x):
- 2-4
- TD32-70 Field of View (HxV) Horizontal:
- 5.7°
- TD62-70 Field of View (HxV) Horizontal:
- 5.6°
- TD32-70 Field of View (HxV) Vertical:
- 5.7°
- TD62-70 Field of View (HxV) Vertical:
- 5.6°
- TD32-70 Field of View (HxV) Diagonal:
- 8°
- TD62-70 Field of View (HxV) Diagonal:
- 7.9°
- Focus range:
- 3m-∞
- Heading:
- Visible Light Sensor
- Type:
- CMOS Sensor
- TD32-70 Resolution(pixel):
- 1920*1080
- TD62-70 Resolution(pixel):
- 2560*1440
- Pixel Size(μm):
- 2.9
- Sensitivity(lux):
- 0.001
- TD32-70 Frame Rate(Hz):
- 60/30
- TD62-70 Frame Rate(Hz):
- 30
- Image Engine:
- PARD VLEA
- Objective Lens(mm):
- 70
- TD32-70 Optical Magnification(x):
- 6.5
- TD62-70 Optical Magnification(x):
- 3.2
- Visible Light Sensor Digital Zoom(x):
- 2
- TD32-70 Continuous Digital Zoom(x):
- 6.5-13
- TD62-70 Continuous Digital Zoom(x):
- 3.2-6.4
- TD32-70 Field of View (HxV) Horizontal:
- 2.6°
- TD62-70 Field of View (HxV) Horizontal:
- 3.4°
- TD32-70 Field of View (HxV) Vertical:
- 2.6°
- TD62-70 Field of View (HxV) Vertical:
- 3.4°
- TD32-70 Field of View (HxV) Diagonal:
- 3.6°
- TD62-70 Field of View (HxV) Diagonal:
- 4.8°
- Visible Light Sensor Focus range:
- 3m-∞
- Heading:
- Display
- Type:
- IPS
- Resolution(pixel):
- 800*800
- Reticle Style:
- 6
- Reticle Color:
- 4(Red/White/Yellow/Green)
- Scene Mode:
- City/Rain/Forest
- Image Mode:
- WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
- Eye Relief(mm):
- 100
- Diopter Adjustment(D):
- -5~+3
- Heading:
- Photo / Video
- Photo Resolution(pixel):
- 2592*1944
- Photo Format:
- .JPG
- Video Resolution(pixel):
- Thermal: 1024*768/Night Vision: 1440*1080
- Video Format:
- .mp4
- Storage(GB):
- Micro SD card (Max. 128)
- Heading:
- Main Function
- LRF Detection Range(yd/m):
- 1200/1000
- PIP:
- Yes
- Gyroscope:
- Yes
- Loop Recording:
- Yes
- Red Dot:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical shutter
- Microphone:
- Yes
- Firmware Upgrade:
- Yes
- Heading:
- IR Illuminator
- IR Type:
- VCSEL
- IR power(W):
- 5
- IR Illuminating Level:
- 3 Levels
- IR Distance(m):
- 350
- IR Wavelength(nm):
- 850/940
- Heading:
- Interfaces
- USB Type-C:
- Yes
- HDMI Output:
- Yes
- Heading:
- Connections
- WiFi:
- Yes
- Supported Apps:
- PardVision
- Heading:
- Power Supply
- Battery type:
- Li-ion 21700*1
- Output Voltage(V):
- 3.7
- Operating Time(h):
- ≤6
- External Power Supply Type:
- Type-C
- Heading:
- Environmental characteristic
- Degree of Protection:
- IP67
- Operating Temp(°C/°F):
- -20 ~ +50 / -4 ~ +122
- Recoil Resistance(J):
- 6000
- Heading:
- Material
- Housing:
- Aluminum Alloy
- Objective lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Product Dimension(L * W * H, mm):
- 350*91*95
- N.W/pcs(without battery, g):
- 800
