The Landsat4 and Landsat6 from PARD combine thermal detection, HD night vision, a ballistics calculator, and laser rangefinder in one unit. Landsat4 uses a 480x360 sensor with 2.1x optical magnification; Landsat6 uses a 640x512 sensor with 1.8x optical magnification. Both have 35mm multi-coated lenses, 12µm pixel pitch, ≤20mK NETD, and detect human-sized targets up to 1800yds (Landsat4) and 2100yds (Landsat6). Night vision is powered by a 2560x1440 CMOS sensor with .001 lux sensitivity and 2.9μm pixel pitch. The VLEA engine supports a 70mm lens, 4.3x base magnification, 2x digital zoom, and 3.4°x3.4° FOV. The 800x800 IPS LCD displays 6 reticle styles, 4 reticle colors, 3 scene modes, 6 thermal options, and 100mm eye relief. It supports photo (2592x1944) and video (1024x768 thermal / 1440x1080 night vision) recording to a 128GB micro SD card (not included). A 1200yd laser rangefinder feeds the ballistics calculator for automatic impact adjustments. PIP mode displays thermal and night vision together. Other features include Wi-Fi (via PardVision2 app), USB-C/HDMI output, IP67 rating, 6000J recoil resistance, -22℉ to 131℉ operation, HOT tracking, gyroscope, compass, microphone, loop recording, and a 26.5 oz (750g) aluminum chassis powered by removable lithium-ion 21700 batteries.
- Models:
- Landsat 480 C, Landsat 640 C
- Classification:
- Multi-spectral Scope
- Heading:
- Thermal Sensor
- Type:
- Uncooled Vox(vanadium oxide)
- Landsat 480 C Resolution(pixel):
- 480*360
- Landsat 640 C Resolution(pixel):
- 640*512
- Pixel Size(µm):
- 12*12
- NETD:
- ≤20mK（0.02℃）
- Frame Rate(Hz):
- 50
- Landsat 480 C Human Detection Distance(m):
- 1800
- Landsat 640 C Human Detection Distance(m):
- 2100
- Image Engine:
- PARD IREA
- Landsat 480 C Objective lens(mm):
- 35
- Landsat 640 C Objective lens(mm):
- 45
- Landsat 480 C Optical Magnification(x):
- 2.5
- Landsat 640 C Optical Magnification(x):
- 2
- Landsat 480 C Digital Zoom(x):
- 2/4/6/8
- Landsat 640 C Digital Zoom(x):
- 2/4/6/8
- Landsat 480 C Field of View (HxV) Horizontal:
- 7.1°
- Landsat 640 C Field of View (HxV) Horizontal:
- 8.8°
- Landsat 480 C Field of View (HxV) Vertical:
- 7.1°
- Landsat 640 C Field of View (HxV) Vertical:
- 8.8°
- Landsat 480 C Field of View (HxV) Diagonal:
- 10.0°
- Landsat 640 C Field of View (HxV) Diagonal:
- 12.4°
- Thermal Sensor Focus range:
- 3m-∞
- Heading:
- Visible Light Sensor
- Landsat 480 C Resolution(pixel):
- 2560*1440
- Landsat 640 C Resolution(pixel):
- 2560*1440
- Pixel Size(μm):
- 2.9
- Sensitivity(lux):
- 0.001
- Frame Rate(Hz):
- Color mode: 60 / Mono: 30
- Image Engine:
- PARD VLEA
- Objective Lens(mm):
- 50/70
- Optical Magnification(x):
- 4.4/6.1
- Digital Zoom(x):
- 2
- Field of View (HxV) Horizontal:
- 4.8°/3.4°
- Field of View (HxV) Vertical:
- 4.8°/3.4°
- Field of View (HxV) Diagonal:
- 6.8°/4.8°
- Visible Light Sensor Focus range:
- 3m-∞
- Heading:
- Display
- Type:
- IPS
- Resolution(pixel):
- 800*800
- Reticle Style:
- 6
- Reticle Color:
- 4(Red/White/Yellow/Green)
- Scene Mode:
- City/Rain/Forest
- Image Mode:
- WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
- Eye Relief(mm):
- 100
- Diopter Adjustment(D):
- -5~+3
- Heading:
- Photo / Video
- Photo Resolution(pixel):
- 1536*1536
- Photo Format:
- .JPG
- Video Resolution(pixel):
- Thermal: 768*768/Night Vision: 1440*1080
- Video Format:
- .mp4
- Storage(GB):
- Micro SD card (Max. 128)
- Heading:
- Main Function
- LRF Detection Range(yd/m):
- 1200/1000
- Ballistic Calculator:
- Yes
- PIP:
- Yes
- Gyroscope:
- Yes
- Loop Recording:
- Yes
- Recoil-activated recording:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical shutter
- Microphone:
- Yes
- Firmware Upgrade:
- Yes
- Heading:
- IR Illuminator
- IR power(W):
- 5
- IR Illuminating Level:
- 3 Levels
- IR Distance(m):
- 350
- IR Wavelength(nm):
- 850/940
- Heading:
- Interfaces
- USB Type-C:
- Yes
- HDMI Output:
- Yes
- Heading:
- Connections
- WiFi:
- Yes
- Supported Apps:
- PardVision2
- Heading:
- Power Supply
- Battery type:
- Li-ion 21700*1
- Output Voltage(V):
- 3.7
- Operating Time(h):
- ≤6
- External Power Supply Type:
- Type-C
- Heading:
- Environmental characteristic
- Degree of Protection:
- IP67
- Operating Temp(°C/°F):
- -20 ~ +50 / -4 ~ +122
- Recoil Resistance(J):
- 6000
- Heading:
- Material
- Housing:
- Aluminum Alloy
- Objective lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Product Dimension(L * W * H, mm):
- 265*92*90
- Landsat 480 C N.W/pcs(with IR illuminator&LRF&battery, g):
- 750
- Landsat 640 C N.W/pcs(with IR illuminator&LRF&battery, g):
- 785
