The DS35-LRF is the first digital night vision scope in the world to use a true 800x800 circular IPS LCD display that provides a natural viewing experience much like a conventional scope. Combined with the CMOS sensor and a lux rating of .001, the resulting resolution is incredible. The patented lens cap provides a free focus design that allows the user to shoot with the lens cap on by viewing through a small hole that controls light transmission through the scope. The 100mm eye relief provides comfort and safety from rifle recoil. It integrates a 1200m laser range finder to accurately calculate range distances and shot placement by automatically feeding the onboard ballistic calculator. Available in either a 50mm or 70mm lens, and with 850nm or 940nm infrared, the DS35-LRF is effective up to 350m. The self-activated video recording feature provides the user the ability to save 20 second video clips to the on-board Micro SD card. Multiple image modes provide adaptability to a variety of environments. The multi-function control knob allows the user to quickly change between functions in a matter of seconds. The entire device is rated IP67 weatherproof to conquer the elements. WIFI connectivity to your Android or IOS device is provided. The DS35-LRF offers 6 digital reticles and 2 colors to personalize to your individual needs. The DS35-LRF uses standard 30mm mounting rings.
- Models:
- DS35 50mm, DS35 70mm
- Heading:
- Sensor
- Resolution(px):
- 2560*1440
- Pixel size(um):
- 2.9um
- Sensitivity(lux):
- 0.001lux
- Frame rate(fps):
- 30fps(night); 60fps (day)
- Image Engine:
- PARD VLEA
- Heading:
- Optics
- DS35 50mm Objective lens:
- 50mm F2.4
- DS35 70mm Objective lens:
- 70mm F2.4
- DS35 50mm Optical Magnification(x):
- 4x
- DS35 70mm Optical Magnification(x):
- 5.6x
- Digital zoom(x):
- 2x
- PIP(x):
- 2x
- DS35 50mm Continuous digital zoom:
- 4-16x
- DS35 70mm Continuous digital zoom:
- 5.6-22.4x
- DS35 50mm Field of view (HxV) Horizontal:
- 4.8º
- DS35 70mm Field of view (HxV) Horizontal:
- 3.4º
- DS35 50mm Field of view (HxV) Vertical:
- 3.6º
- DS35 70mm Field of view (HxV) Vertical:
- 3.4º second?
- DS35 50mm Field of view (HxV) Diagonal:
- 5.1º
- DS35 70mm Field of view (HxV) Diagonal:
- 4.8º
- Focus range:
- 5m-∞
- Eye relief(mm):
- 100mm
- Exit pupil(mm):
- 10mm
- Diopter adjustment(°):
- -3D~+5D
- Heading:
- IR Illuminator
- IR Type:
- VCSEL
- IR power:
- 5W
- IR illuminating level:
- 3 levels
- IR distance(m):
- 350m
- IR Wavelength(nm):
- 850nm/940nm
- Heading:
- Display
- Type:
- IPS LCD
- Resolution(px):
- 800*800
- Reticle Style:
- 6
- Reticle Color:
- white,yellow,green
- Color mode:
- Color,Mono BW,Mono Green,Mono Yellow
- Heading:
- Photo / Video
- DS35 50mm Photo resolution(px):
- 1920*1080
- DS35 70mm Photo resolution(px):
- 2560*1440
- Photo format:
- JPG
- Video resolution(px):
- 1920*1080
- Video format:
- MP4
- Storage(GB):
- TF card(128GB)
- Heading:
- Main function
- PIP:
- Yes
- LRF detection range(yds):
- 1200yds(LRF version)
- Ballistic calculator:
- Yes
- Range unit selection:
- meter/yard
- Gyroscope:
- Yes
- Self-activated recording:
- Yes
- Auto recording:
- Yes
- Loop recording:
- Yes
- Time stamp:
- Yes
- Record audio:
- Yes
- Beep sound:
- Yes
- Exposure compensation:
- Yes
- Heading:
- Interfaces
- USB Type-C:
- TYPE C
- HDMI Output:
- Yes
- Heading:
- Connections
- WiFi:
- Yes
- Supported Apps:
- PardVision
- Heading:
- Power Supply
- Battery type:
- Lithium Ion18650
- Output voltage(V):
- 3.7
- Operating time(h,max):
- 8
- External power supply(V):
- USB Type-C
- Heading:
- Environmental characteristic
- Degree of protection:
- IP67
- Operating temp(°C):
- -20 – 50
- Recoil Power(J):
- 1000G
- Heading:
- Material
- Housing:
- Aluminium Alloy
- Objective lens:
- Glass
- Heading:
- Measurement
- Product dimension(L x W x H, mm):
- L350mm*W88mm*H95mm(W/O Long Eyepiece) L410mm*W88mm*H95mm(W/ Long Eyepiece)
- N.W/pcs(without battery, g):
- 680g(W/O Battery)
