The Merlin ME-50/850 binoculars are equipped with a 1920 × 1080 CMOS sensor and 0.001 lux sensitivity for clear low-light performance. With 4.6x to 9.2x magnification and a picture-in-picture (PIP) mode extending up to 18.4x, they deliver detailed long-range viewing. A 350-meter IR illumination range enhances visibility in the dark, making them a dependable tool for nighttime observation.
- Model:
- Merlin
- Heading:
- Sensor
- Sensor Type:
- CMOS
- Sensor Resolution(pixel):
- 1920*1080
- Pixel size(μm):
- 2.9
- Sensitivity(lux):
- 0.0001
- Frame rate(Hz):
- 60(Color)/30(B&W)
- Image Engine:
- PARD VLEA
- Heading:
- Optics
- Objective lens(mm):
- 35/50
- Optical Magnification(x):
- 3.2/4.6
- Digital zoom(x):
- 2
- Horizontal Field of view (HxV):
- 6.8°/4.8°
- Vertical Field of view (HxV):
- 5.1°/3.6°
- Diagonal Field of view (HxV):
- 8.5°/6.0°
- Focus range:
- 3m-∞
- Diopter adjustment(D):
- -5~3
- Heading:
- IR Illuminator
- IR Type:
- VCSEL
- IR power(W):
- 5
- IR illuminating level:
- 3 Levels
- IR distance(m):
- 350
- IR Wavelength(nm):
- 850/940
- Heading:
- Display
- Display Type:
- OLED
- Display Resolution(pixel):
- 640*480
- Color mode:
- Color/Black&White
- Heading:
- Main function
- PIP:
- Yes
- Auto recording:
- Yes
- Loop recording:
- Yes
- Time stamp:
- Yes
- Record audio:
- Yes
- Exposure compensation:
- Yes
- Storage(GB):
- Micro SD card (Max. 128GB)
- Heading:
- Connections
- USB Type-C:
- Yes
- WiFi:
- Yes
- Supported Apps:
- PardVision2
- Heading:
- Power Supply
- Battery type:
- Lithium Ion 21700*1
- Output voltage(V):
- 3.7
- Operating time(h,max):
- 6
- External power supply(V):
- Type-C
- Heading:
- Environmental characteristic
- Degree of protection:
- IP67
- Operating temp(°C/°F):
- -30 ~ +55 / -22 ~ +131
- Heading:
- Material
- Housing:
- AL6061 & Composite
- Objective lens:
- Glass
- Heading:
- Measurement
- Product dimension(L x W x H, mm):
- 220*137*58
- N.W/pcs(with/without battery, g):
- 441.6
1 Review Hide Reviews Show Reviews
-
Sample Review Title
This is a sample review for the product.
Sharp Vision & True Low-Light Performance
Delivering 1920x1080 resolution, this CMOS sensor captures ultra-clear images with fine detail. Its 0.001 lux sensitivity ensures visibility in extreme darkness—making it ideal for night patrols, wildlife observation, or tactical missions.
Zoom in with Precision—Up to 18.4x in PIP
Start wide at 4.6x, go closer at 9.2x, and use PIP mode to push up to 18.4x for detailed target inspection. This system offers smooth magnification transitions and layered visual control, giving you full command of every viewing scenario.
