The NV009 comes equipped with a 35mm lens that is ideal for gathering light that the 1920x1080 CMOS sensor uses to amplify images that are viewable on the 1024x768 OLED display. Additional features of the NV009 include IP67 weatherproof ratings, high resolution video and photo resolutions, PIP (Picture in Picture) mode, removable 128GB micro SD card, rechargeable/removable 18650 Li- Ion batteries, electronic compass, WIFI connectivity to your phone through the PardVision app, aluminum construction and multiple image color modes.
- Models:
- NV009
- Heading:
- Sensor
- Sensor Type:
- CMOS
- Sensor Resolution(pixel):
- 1920*1080
- Pixel size(μm):
- 2.9
- Sensitivity(lux):
- 0.001
- Frame rate(Hz):
- 60/30
- Image Engine:
- PARD VLEA
- Heading:
- Optics
- Objective lens(mm):
- 35
- Optical Magnification(x):
- 4.7
- Digital zoom(x):
- 1.5-3.0
- Continuous digital zoom(x):
- 7~14
- Horizontal Field of view (HxV):
- 9.1°
- Vertical Field of view (HxV):
- 5.1°
- Diagonal Field of view (HxV):
- 10.4°
- Focus range:
- 3m-∞
- Eye relief(mm):
- 25
- Exit pupil(mm):
- 6
- Diopter adjustment(D):
- ± 5D
- Heading:
- IR Illuminator
- IR Type:
- VCSEL
- IR power(W):
- 5
- IR illuminating level:
- 3 Levels
- IR distance(m):
- 200
- IR Wavelength(nm):
- 850/940
- Heading:
- Display
- Display Type:
- OLED
- Display Resolution(pixel):
- 1024*768
- Color mode:
- Color/Black&white
- Heading:
- Photo / Video
- Photo resolution(pixel):
- 2592*1944
- Photo format:
- .JPG
- Video resolution(pixel):
- 1920*1080
- Video format:
- .mp4
- Storage(GB):
- Micro SD card (Max. 128GB)
- Heading:
- Main function
- PIP:
- Yes
- E-compass:
- Yes
- Auto recording:
- Yes
- Loop recording:
- Yes
- Time stamp:
- Yes
- Record audio:
- Yes
- Beep sound:
- Yes
- Exposure compensation:
- Yes
- Heading:
- Connections
- USB Type-C:
- Yes
- HDMI Output:
- Yes
- WiFi:
- Yes
- Supported Apps:
- PardVision
- Heading:
- Power Supply
- Battery type:
- 18650 Li-ion*1
- Output voltage(V):
- 3.7
- Operating time(h,max):
- 8
- External power supply(V):
- USB Type-C
- Heading:
- Environmental characteristic
- Degree of protection:
- IP67
- Operating temp(°C/°F):
- -20 ~ +50 / -4 ~ +122
- Heading:
- Material
- Housing:
- AL6061 & Composite
- Objective lens:
- Glass
- Heading:
- Measurement
- Product dimension(L x W x H, mm):
- 150 x 70 x 38
- N.W/pcs(with/without battery, g):
- 260/306
