The DS35-LRF is the first digital night vision scope in the world to use a true 800x800 circular IPS LCD display that provides a natural viewing experience much like a conventional scope. Combined with the CMOS sensor and a lux rating of .001, the resulting resolution is incredible. The patented lens cap provides a free focus design that allows the user to shoot with the lens cap on by viewing through a small hole that controls light transmission through the scope. The 100mm eye relief provides comfort and safety from rifle recoil. It integrates a 1200m laser range finder to accurately calculate range distances and shot placement by automatically feeding the onboard ballistic calculator. Available in either a 50mm or 70mm lens, and with 850nm or 940nm infrared, the DS35-LRF is effective up to 350m. The self-activated video recording feature provides the user the ability to save 20 second video clips to the on-board Micro SD card. Multiple image modes provide adaptability to a variety of environments. The multi-function control knob allows the user to quickly change between functions in a matter of seconds. The entire device is rated IP67 weatherproof to conquer the elements. WIFI connectivity to your Android or IOS device is provided. The DS35-LRF offers 6 digital reticles and 2 colors to personalize to your individual needs. The DS35-LRF uses standard 30mm mounting rings.
- Models:
- DS35 50mm, DS35 70mm
- Heading:
- Sensor
- Resolution(px):
- 2560*1440
- Pixel size(um):
- 2.9um
- Sensitivity(lux):
- 0.001lux
- Frame rate(fps):
- 30fps(night); 60fps (day)
- Image Engine:
- PARD VLEA
- Heading:
- Optics
- DS35 50mm Objective lens:
- 50mm F2.4
- DS35 70mm Objective lens:
- 70mm F2.4
- DS35 50mm Optical Magnification(x):
- 4x
- DS35 70mm Optical Magnification(x):
- 5.6x
- Digital zoom(x):
- 2x
- PIP(x):
- 2x
- DS35 50mm Continuous digital zoom:
- 4-16x
- DS35 70mm Continuous digital zoom:
- 5.6-22.4x
- DS35 50mm Field of view (HxV) Horizontal:
- 4.8º
- DS35 70mm Field of view (HxV) Horizontal:
- 3.4º
- DS35 50mm Field of view (HxV) Vertical:
- 3.6º
- DS35 70mm Field of view (HxV) Vertical:
- 3.4º second?
- DS35 50mm Field of view (HxV) Diagonal:
- 5.1º
- DS35 70mm Field of view (HxV) Diagonal:
- 4.8º
- Focus range:
- 5m-∞
- Eye relief(mm):
- 100mm
- Exit pupil(mm):
- 10mm
- Diopter adjustment(°):
- -3D~+5D
- Heading:
- IR Illuminator
- IR Type:
- VCSEL
- IR power:
- 5W
- IR illuminating level:
- 3 levels
- IR distance(m):
- 350m
- IR Wavelength(nm):
- 850nm/940nm
- Heading:
- Display
- Type:
- IPS LCD
- Resolution(px):
- 800*800
- Reticle Style:
- 6
- Reticle Color:
- white,yellow,green
- Color mode:
- Color,Mono BW,Mono Green,Mono Yellow
- Heading:
- Photo / Video
- DS35 50mm Photo resolution(px):
- 1920*1080
- DS35 70mm Photo resolution(px):
- 2560*1440
- Photo format:
- JPG
- Video resolution(px):
- 1920*1080
- Video format:
- MP4
- Storage(GB):
- TF card(128GB)
- Heading:
- Main function
- PIP:
- Yes
- LRF detection range(yds):
- 1200yds(LRF version)
- Ballistic calculator:
- Yes
- Range unit selection:
- meter/yard
- Gyroscope:
- Yes
- Self-activated recording:
- Yes
- Auto recording:
- Yes
- Loop recording:
- Yes
- Time stamp:
- Yes
- Record audio:
- Yes
- Beep sound:
- Yes
- Exposure compensation:
- Yes
- Heading:
- Interfaces
- USB Type-C:
- TYPE C
- HDMI Output:
- Yes
- Heading:
- Connections
- WiFi:
- Yes
- Supported Apps:
- PardVision
- Heading:
- Power Supply
- Battery type:
- Lithium Ion18650
- Output voltage(V):
- 3.7
- Operating time(h,max):
- 8
- External power supply(V):
- USB Type-C
- Heading:
- Environmental characteristic
- Degree of protection:
- IP67
- Operating temp(°C):
- -20 – 50
- Recoil Power(J):
- 6000
- Heading:
- Material
- Housing:
- Aluminium Alloy
- Objective lens:
- Glass
- Heading:
- Measurement
- Product dimension(L x W x H, mm):
- L350mm*W88mm*H95mm(W/O Long Eyepiece) L410mm*W88mm*H95mm(W/ Long Eyepiece)
- N.W/pcs(without battery, g):
- 680g(W/O Battery)
1 Review Hide Reviews Show Reviews
-
PARD DS35 LRF
I like this scope. It works day or night. It can record videos and take photos of your shots in high definition. The built in laser range finder that tells you the exact distance to your target (up to 1,200 yards). Great tech at a fair price point. I recommend.
