The Pantera 640-Zoom w/LRF features a 640×512 resolution sensor with 12μm pixel pitch and a high-sensitivity sensor (NETD ≤ 20mK) for crisp thermal imaging. Its optical zoom ranges from 1.3x to 2.5x, with an 8x digital zoom for extended viewing. The system includes a built-in laser range finder (LRF) with a 1200-yard range and integrated ballistic calculator, all displayed through the world’s first TRUE circular display with 100mm eye relief.
- Models:
- Pantera 480, Pantera 640
- Classification:
- Thermal Imaging Scope
- Heading:
- Thermal Sensor
- Type:
- Uncooled VOx(vanadium oxide)
- Pantera 480 Resolution(pixel):
- 480*360
- Pantera 640 Resolution(pixel):
- 640*512
- Pixel Size(µm):
- 12*12
- NETD:
- ≤20mK（0.02℃）
- Frame Rate(Hz):
- 50
- Pantera 480 Detection Distance(m):
- 1800/2600
- Pantera 640 Detection Distance(m):
- 2600/3900
- Heading:
- Optics
- Pantera 480 Objective lens(mm):
- 35/50
- Pantera 640 Objective lens(mm):
- 50/75
- Pantera 480 Optical Magnification(x):
- 2.1/3.0
- Pantera 640 Optical Magnification(x):
- 2.2/3.3
- Digital Zoom(x):
- 2/4/6/8
- Pantera 480 Field of View (HxV) Horizontal:
- 7.1°/5.0°
- Pantera 640 Field of View (HxV) Horizontal:
- 7.0°/4.7°
- Pantera 480 Field of View (HxV) Vertical:
- 7.1°/5.0°
- Pantera 640 Field of View (HxV) Vertical:
- 7.0°/4.7°
- Pantera 480 Field of View (HxV) Diagonal:
- 10.0°/7.0°
- Pantera 640 Field of View (HxV) Diagonal:
- 9.9°/6.6°
- Eye Relief(mm):
- 100
- Diopter Adjustment(D):
- -5~+3
- Type:
- IPS
- Resolution(pixel):
- 800*800
- Reticle Style:
- 6
- Reticle Color:
- Red/White/Yellow/Green
- Scene Mode:
- City/Rain/Forest
- Image mode:
- WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
- Heading:
- Photo / Video
- Photo Resolution(pixel):
- 1536*1536
- Photo Format:
- .JPG
- Video Resolution(pixel):
- 768*768
- Video Format:
- .mp4
- Storage(GB):
- Micro SD card(Max. 128)
- Image Engine:
- Pard IREA
- Heading:
- Main function
- LRF detection range(m/yd):
- 1000/1200
- Ballistic Calculator:
- Yes
- PIP:
- Yes
- Hot Track:
- Yes
- Gyroscope:
- Yes
- Recoil-activated recording:
- Yes
- Loop Recording:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical Shutter
- Microphone:
- Yes
- Firmware Upgrade:
- Yes
- Heading:
- Connections
- USB Tpye-C:
- Yes
- HDMI Output:
- Yes
- WiFi:
- Yes
- Supported Apps:
- PardVision2
- Heading:
- Power Supply
- Battery Type:
- Lithium Ion 18650*1
- Output Voltage(V):
- 3.7
- Operating Time(h):
- ≤6
- External power supply(V):
- Type-C
- Heading:
- Environmental characteristic
- Degree of protection:
- IP67
- Operating Temp(°C/°F):
- -30 ~ +55 / -22 ~ +131
- Recoil Resistance(J):
- 6000
- Heading:
- Material
- Housing:
- Aluminum Alloy
- Objective Lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Pantera 480 Product Dimension/with LRF(L * W * H, mm):
- "Pantera 480-35mm Lens: 352*93*82 Pantera 480-50mm Lens: 364*93*82"
- Pantera 640 Product Dimension/with LRF(L * W * H, mm):
- "Pantera 640-50mm Lens： 364*93*82 Pantera 640-75mm Lens： TBD"
- Pantera 480 N.W/pcs(with LRF&battery, g):
- "Pantera 480-35mm Lens: 622 Pantera 480-50mm Lens: 681.5"
- Pantera 640 N.W/pcs(with LRF&battery, g):
- "Pantera 640-50mm Lens： 681.5 Pantera 640-75mm Lens： TBD"
