The Ocelot 640-Zoom features 1.3x–2.5x optical zoom with 8x digital zoom and 640x512 sensor resolution. It has the world’s first true circular display with 100mm eye relief and a built-in laser range finder (LRF) with a 1200-yard range, integrated with a ballistic calculator for accurate targeting.
- Models:
- Ocelot Zoom
- Heading:
- Sensor
- Type:
- Uncooled VOx(vanadium oxide)
- Resolution(pixel):
- 640*512
- Pixel Size(µm):
- 12*12
- NETD:
- ≤20mK（0.02℃）
- Frame Rate(Hz):
- 50
- Detection Distance(m):
- 1200/2600
- Heading:
- Optics
- Objective Lens(mm):
- 25/50
- Optical Magnification(x):
- 1.3/2.5
- Digital Zoom(x):
- 2/4/6/8
- Field of view Horizontal:
- 14.0°/7.0°
- Field of view Vertical:
- 14.0°/7.0°
- Field of view Diagonal:
- 19.8°/9.9°
- Eye Relief(mm):
- 100
- Diopter Adjustment(D):
- -5~+3
- Heading:
- Display
- Type:
- IPS
- Resolution(pixel):
- 800*800
- Reticle style:
- 6
- Reticle color:
- 4(Red/White/Yellow/Green)
- Scene Mode:
- City/Rain/Forest
- Image Mode:
- WT-HOT/BK-HOT/RD-HOT/IN-HOT/SKY
- Heading:
- Photo / Video
- Photo Resolution(pixel):
- 1536*1536
- Photo Format:
- .JPG
- Video Resolution(pixel):
- 768*768
- Video Format:
- .mp4
- Storage:
- Micro SD card(Max 128GB)
- Image Engine:
- Pard IREA
- Heading:
- Main Function
- LRF Detection Range(m/yd):
- 1000/1200
- Ballistic Calculator:
- Yes
- PIP:
- Yes
- Gyroscope:
- Yes
- Recoil-activated Recording:
- Yes
- Loop Recording:
- Yes
- Red Dot:
- No
- Hot Track:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical Shutter
- Microphone:
- Yes
- Firmware Upgrade:
- Yes
- Heading:
- Connections
- USB Type-C:
- Yes
- HDMI Output HDMI:
- Yes
- WiFi:
- Yes
- Support Apps:
- PardVision2
- Heading:
- Power Supply
- Battery Type:
- Lithium 21700*1
- Output Voltage(V):
- 3.7
- Operating Time(h):
- ≤6
- External Power Supply:
- Type-C
- Heading:
- Environmental Characteristic
- Protective Class:
- IP67
- Operating Temp(℃/°F):
- -30 ~ +55 / -22 ~ +131
- Recoil Resistance(J):
- 6000
- Heading:
- Material
- Housing:
- Aluminum Alloy
- Objective Lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Product Dimension/with LRF(L*W*H,mm):
- 182*68*79
- N.W/pcs(with LRF&battery,g):
- 709
