Continuing the legacy, the Bobcat (640 & 480) is lightweight, ergonomically friendly, and provides cutting-edge optics through state-of-the-art electronics. Equipped with an all-new generation sensor (NETD ≤ 18mk), the Bobcat detects even the smallest thermal differences with ease and delivers exceptional imagery to the end user. The 1920x1080 OLED display offers enhanced brightness, sharper resolution, and superior contrast compared to traditional LCD screens. Whether you're in the field or on the move, it's built to go anywhere without slowing you down. Compact. Capable. Ready.
- Models:
- Bobcat 480, Bobcat 640
- Classification:
- Thermal Imaging monocular
- Heading:
- Sensor
- Sensor Type:
- Uncooled VOx (vanadium oxide)
- 480 Sensor Resolution(pixel):
- 480*360
- 640 Sensor Resolution(pixel):
- 640*512
- Pixel size(μm):
- 12*12
- Sensitivity(lux):
- ≤18mK（0.018℃)
- Frame rate(Hz):
- 50
- Frame rate(Hz):
- 1800
- Heading:
- Optics
- Objective lens(mm):
- 35
- 480 Optical Magnification(x):
- 3.5
- 640 Optical Magnification(x):
- 2.6
- Digital zoom(x):
- 2/4/6/8
- 480 Horizontal Field of view(°):
- 9.4
- 480 Vertical Field of view(°):
- 7.1
- 480 Diagonal Field of view(°):
- 11.7
- 640 Horizontal Field of view(°):
- 12.5
- 640 Vertical Field of view(°):
- 10
- 640 Diagonal Field of view(°):
- 16
- 480 Horizontal Field of view (m @100m):
- 16.5
- 480 Vertical Field of view (m @100m):
- 12.3
- 640 Horizonal Field of view (m @100m):
- 21.9
- 640 Vertical Field of view (m @100m):
- 17.6
- Focus range:
- 3m ~ ∞
- Diopter adjustment(D):
- ±5D
- Heading:
- Display
- Display Type:
- OLED
- Display Resolution(pixel):
- 1920*1080
- Image mode:
- WT-HOT/BK-HOT/H-light/RD-HOT/IN-HOT/SKY
- Heading:
- Video & Photo
- Photo Resolution(pixel):
- 1440*1080
- Photo Format:
- .JPG
- Video Resolution(pixel):
- 1440*1080
- Video Format:
- .mp4
- Heading:
- Main function
- LRF/m:
- 1000
- Compass:
- Yes
- PIP:
- Yes
- Auto recording:
- Yes
- Loop recording:
- Yes
- Time stamp:
- Yes
- Record audio:
- Yes
- Storage(GB):
- Micro SD card (Max. 128GB)
- Heading:
- Connections
- USB Type-C:
- Yes
- WiFi:
- Yes
- Supported Apps:
- PardVision2
- Heading:
- Power Supply
- Battery type:
- Li-ion Battery 18650*1
- Output voltage(V):
- 3.7
- Output voltage(V):
- 6
- External power supply:
- Type-C
- Heading:
- Material
- Housing:
- AL6061 & Composite
- Objective lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Product dimension(L x W x H, mm):
- 170*70*43
- N.W/pcs(with battery, g):
- 405
