The PARD TD32 and TD62 Multi-Spectral Scopes combine thermal imaging and digital night vision into a single, high-performance optical system that excels in any lighting condition. Both models feature Picture-in-Picture (PIP) mode, enabling users to view thermal and night vision simultaneously on an ultra-clear 800x800 IPS LCD display.
Each unit includes a 1200-yard laser rangefinder (LRF) paired with a built-in ballistics calculator, automatically adjusting the reticle for precise point-of-impact correction. The visible light sensor (1920x1080 CMOS) delivers crisp imagery in low light, reaching sensitivity levels down to 0.001 lux, supported by a 70mm objective lens and VCSEL IR illuminator with three brightness settings and a 383-yard (350m) beam.
Rugged and reliable, the TD Series offers IP67-rated protection, 6000J recoil resistance, and operational reliability from -4°F to 122°F. Additional features include Wi-Fi connectivity via the PardVision app, USB-C and HDMI output, photo/video recording to a removable 128GB micro SD card, and a lightweight 28oz (800g) chassis.
Model Differences
The TD32 utilizes a 384x288 thermal sensor, offering dependable detection performance and crisp imaging for mid-range observation. It’s an excellent choice for hunters and professionals seeking an efficient, all-in-one thermal and night vision platform without compromising on image fidelity.
The TD62 steps up to a 640x512 uncooled Vox IR sensor, delivering finer target detail, higher contrast, and superior recognition at extended ranges. It’s designed for users who demand elite imaging accuracy and situational clarity, whether scanning open terrain or engaging in tactical operations.
Shipping: Confirmed orders will be shipped within 2 business days from our US warehouse
Warranty: 3 Years for Thermal Imaging models & 2 years for Night Vision models
- Models:
- TD32-70, TD62-70
- Classification:
- Multi-spectral Thermal/Night Vision Scope.
- Heading:
- Thermal Sensor
- Type:
- Uncooled Vox IR Sensor
- TD32-70 Resolution(pixel):
- 384*288
- TD62-70 Resolution(pixel):
- 640*512
- TD32-70 Pixel Size(µm):
- 12*12
- TD62-70 Pixel Size(µm):
- 12*12
- NETD:
- ≤25mK（0.025℃）
- Frame Rate(Hz):
- 50
- TD32-70 Human Detection Distance(m):
- 1400
- TD62-70 Human Detection Distance(m):
- 1800
- TD32-70 Vehicle Detection Distance(m):
- 2600
- TD62-70 Vehicle Detection Distance(m):
- 3300
- Image Engine:
- PARD IREA
- TD32-70 Objective lens(mm):
- 35
- TD62-70 Objective lens(mm):
- 45
- TD32-70 Optical Magnification(x):
- 3
- TD62-70 Optical Magnification(x):
- 2
- Thermal Sensor Digital Zoom(x):
- 2
- TD32-70 Continuous Digital Zoom(x):
- 3-6
- TD62-70 Continuous Digital Zoom(x):
- 2-4
- TD32-70 Field of View (HxV) Horizontal:
- 5.7°
- TD62-70 Field of View (HxV) Horizontal:
- 5.6°
- TD32-70 Field of View (HxV) Vertical:
- 5.7°
- TD62-70 Field of View (HxV) Vertical:
- 5.6°
- TD32-70 Field of View (HxV) Diagonal:
- 8°
- TD62-70 Field of View (HxV) Diagonal:
- 7.9°
- Focus range:
- 3m-∞
- Heading:
- Visible Light Sensor
- Type:
- CMOS Sensor
- TD32-70 Resolution(pixel):
- 1920*1080
- TD62-70 Resolution(pixel):
- 2560*1440
- Pixel Size(μm):
- 2.9
- Sensitivity(lux):
- 0.001
- TD32-70 Frame Rate(Hz):
- 60/30
- TD62-70 Frame Rate(Hz):
- 30
- Image Engine:
- PARD VLEA
- Objective Lens(mm):
- 70
- TD32-70 Optical Magnification(x):
- 6.5
- TD62-70 Optical Magnification(x):
- 3.2
- Visible Light Sensor Digital Zoom(x):
- 2
- TD32-70 Continuous Digital Zoom(x):
- 6.5-13
- TD62-70 Continuous Digital Zoom(x):
- 3.2-6.4
- TD32-70 Field of View (HxV) Horizontal:
- 2.6°
- TD62-70 Field of View (HxV) Horizontal:
- 3.4°
- TD32-70 Field of View (HxV) Vertical:
- 2.6°
- TD62-70 Field of View (HxV) Vertical:
- 3.4°
- TD32-70 Field of View (HxV) Diagonal:
- 3.6°
- TD62-70 Field of View (HxV) Diagonal:
- 4.8°
- Visible Light Sensor Focus range:
- 3m-∞
- Heading:
- Display
- Type:
- IPS
- Resolution(pixel):
- 800*800
- Reticle Style:
- 6
- Reticle Color:
- 4(Red/White/Yellow/Green)
- Scene Mode:
- City/Rain/Forest
- Image Mode:
- WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY
- Eye Relief(mm):
- 100
- Diopter Adjustment(D):
- -5~+3
- Heading:
- Photo / Video
- Photo Resolution(pixel):
- 2592*1944
- Photo Format:
- .JPG
- Video Resolution(pixel):
- Thermal: 1024*768/Night Vision: 1440*1080
- Video Format:
- .mp4
- Storage(GB):
- Micro SD card (Max. 128)
- Heading:
- Main Function
- LRF Detection Range(yd/m):
- 1200/1000
- PIP:
- Yes
- Gyroscope:
- Yes
- Loop Recording:
- Yes
- Red Dot:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical shutter
- Microphone:
- Yes
- Firmware Upgrade:
- Yes
- Heading:
- IR Illuminator
- IR Type:
- VCSEL
- IR power(W):
- 5
- IR Illuminating Level:
- 3 Levels
- IR Distance(m):
- 350
- IR Wavelength(nm):
- 850/940
- Heading:
- Interfaces
- USB Type-C:
- Yes
- HDMI Output:
- Yes
- Heading:
- Connections
- WiFi:
- Yes
- Supported Apps:
- PardVision
- Heading:
- Power Supply
- Battery type:
- Li-ion 21700*1
- Output Voltage(V):
- 3.7
- Operating Time(h):
- ≤6
- External Power Supply Type:
- Type-C
- Heading:
- Environmental characteristic
- Degree of Protection:
- IP67
- Operating Temp(°C/°F):
- -20 ~ +50 / -4 ~ +122
- Recoil Resistance(J):
- 6000
- Heading:
- Material
- Housing:
- Aluminum Alloy
- Objective lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- Product Dimension(L * W * H, mm):
- 350*91*95
- N.W/pcs(without battery, g):
- 800
