The SA-LRF family of digital thermal rifle scopes highlight BIG features in a small package. It is a compact and powerful thermal imaging rifle scope, available in either 35mm or 45mm lenses, and 384x288 or 640x480 resolution. The SA-LRF is streamlined, balanced and lightweight. At only 16 oz (455g), it easily mounts on your favorite rifle with the included aircraft grade aluminum cantilever mount. The display features a a crisp 1024x768 OLED screen, backing up the vanadium oxide thermal sensor allowing the SA-LRF to detect and identify targets out to 1800yds. With a pixel pitch of 12μm (microns) and a Noise Equivalent Temperature Difference (NETD) of ≤25mK, you get an extremely sensitive device that performs even when environmental thermal contrast is low. The SA-LRF offers five thermal display colors for varying conditions and a refresh rate of 50 Hz. The 18650 removable/rechargeable battery provides up to 5 hours of use and can operate in temperatures between -4° and 122° F. The Ingress Protection (IP) factor rates at an industry leading IP67, providing 100 percent security against dust and submersion in up to 3ft of water. The SA-LRF also integrates many technologically advanced features such as a ballistics calculator, One-Shot Zero, PIP mode, Blind Pixel supplementation correction, Time/Date image stamp, Auto Hot target tracking, Wi-Fi connectivity to your mobile device and 1024x768 video recording for your shot record that can be saved to the removable 128GB Micro SD card. 2592x1944 high resolution digital images can also be captured with the SA-LRF.
- Models:
- SA32(LRF), SA62(LRF)
- Heading:
- Sensor
- Type:
- uncooled VOx(vanadium oxide)
- SA32(LRF) Resolution(px):
- 384*288
- SA62(LRF) Resolution(px):
- 640*480
- Pixel size(µm):
- 12μm*12μm
- NETD(mK):
- ≤25mK(0.025℃)
- Frame rate(Hz):
- 50Hz
- SA32(LRF) Human detection distance(m):
- 800/1100/1400/1700
- SA62(LRF) Human detection distance(m):
- 1200/1500/1800
- SA32(LRF) Vehicle detection distance(m):
- 1800/2200/2600/3000
- SA62(LRF) Vehicle detection distance(m):
- 2500/2900/3300
- Heading:
- Optics
- SA32(LRF) Objective lens:
- 19mm/25mm/35mm/45mm
- SA62(LRF) Objective lens:
- 25mm/35mm/45mm
- SA32 Optical Magnification(x):
- 2x/2.6x/3.7x/4.7x
- SA62 Optical Magnification(x):
- 1.6x/2.2x/2.8x
- Digital zoom(x):
- 2-8x
- PIP Zoom(x):
- 2X
- SA32 Continuous digital zoom:
- 2-32X/2.6-41.6X/3.7-59.2X/4.7-75.2X
- SA62 Continuous digital zoom:
- 1.6-25.6X/2.2-35.2X/2.8-44.8X
- SA32 Field of view (HxV):
- 13.8°/10.5°/7.5°/5.9°
- SA62 Field of view (HxV):
- 17.5/12.5°/9.7°
- SA32 Field of view (HxV):
- 10.4°/7.9°/5.6°/4.4°
- SA62 Field of view (HxV):
- 13.1°/9.4°/7.3°
- SA32 Field of view (HxV):
- 17.2°/13.1°/9.4°/7.3°
- SA62 Field of view (HxV):
- 21.7°/15.6°/12.2°
- Eye relief(mm):
- 30mm
- Diopter adjustment(D):
- - 5D~+5D
- Heading:
- Display
- Type:
- OLED
- Resolution(px):
- 1024*768
- Reticle Style:
- 6
- Reticle Color:
- 4(Red,White,Yellow,Green)
- Scene Mode:
- City,Rain,Forest
- Image mode:
- WT-HOT,BK-HOT,EDGE,RD-HOT,IN-HOT,Sky
- Heading:
- Photo / Video
- Photo resolution(px):
- 2592*1944
- Photo format:
- .JPG
- Video resolution(px):
- 1024*768
- Video format:
- .mp4
- Storage(GB):
- TF card(128 GB)(Max)
- Image Engine:
- Pard IREA
- Heading:
- Main function
- LRF detection range(yds):
- 1200yds
- Ballistic calculator:
- Yes
- PIP:
- Yes
- Gyroscope:
- Yes
- Self-motivated recording:
- Yes
- Loop recording:
- Yes
- Red dot:
- Yes
- E-compass:
- Yes
- Shutter:
- Mechanical shutter
- Microphone:
- Yes
- Illuminator:
- 1W(350mA)
- Firmware Upgrade:
- Yes
- Heading:
- Interfaces
- USB Tpye-C:
- Yes
- HDMI Output:
- Yes
- Heading:
- Connections
- WiFi:
- Yes
- Supported Apps:
- PardVision
- Heading:
- Power Supply
- Battery type:
- Lithium Ion 18650*1
- Output voltage(V):
- 3.7V
- Operating time(h):
- ≤5h
- External power supply(V):
- Type-C
- Heading:
- Environmental characteristic
- Degree of protection:
- IP67
- Operating temp(°C):
- -20℃~50℃
- Recoil Power(J)/shcok resistance(G):
- 1000G
- Heading:
- Material
- Housing:
- Aluminium Alloy
- Objective lens:
- All-glass multi-coated lens
- Heading:
- Measurement
- SA32 (LRF)Product dimension(L x W x H, mm):
- SA32:195*77*56mm SA32 LRF:195*79*59mm
- SA62(LRF) Product dimension(L x W x H, mm):
- SA62:195*77*56mm SA62 LRF:195*79*59mm
- SA32 (LRF) N.W/pcs(without battery, g):
- SA32 :425g SA32 LRF :455g
- SA62(LRF) N.W/pcs(without battery, g):
- SA62 :425g SA62 LRF :455g
